阿普奇 IPC330D-H81L5 | 4/5th 5網口4個PoE 緊湊型壁掛式工控機
產品描述
阿普奇 IPC330D-H81L5 是IPC330系列壁掛式工控機中的多網口PoE型號。采用緊湊型壁掛式機箱設計（IPC330系列），適合墻壁、機柜側面或設備內部安裝。
核心配置：Intel 4/5代酷睿桌面處理器，H81芯片組，2×SO-DIMM DDR3雙通道1600MHz（筆記本內存）。網絡是該型號的最大特色——5路Intel千兆網口，其中4路采用i210-AT芯片并配備PoE供電接口，可直接為IP攝像頭、無線AP等PoE設備供電；另1路為i218-LM/V管理網口。存儲提供1×SATA3.0 + 1×SATA2.0 + 1×mSATA（SATA3.0，與Mini PCIe共用槽位）。
擴展方面：1×PCIe x16（Gen2）全高槽位可安裝視頻采集卡或AI加速卡，1×Mini PCIe（與mSATA共用，含SIM卡槽）可安裝4G/5G通信模塊。I/O方面提供6路COM（2路RS232/422/485 BIOS切換），HDMI1.4（2560×1440@60Hz），前置2×USB 5Gbps + 4×USB2.0。
4路PoE供電+5路千兆網口使IPC330D-H81L5成為緊湊型工業NVR、多網口網關和IP攝像頭管理節點的理想選擇。
|
Model |
IPC330D-H81L5 |
|
|
Processor System |
CPU | ?Support Intel? 4/5th Generation Core / Pentium/ Celeron Desktop CPU |
| ? | TDP | ?95W |
| ? | Socket | ?LGA1150 |
| ? | Chipset | ?H81 |
| ? | BIOS | ?AMI 256 Mbit SPI |
|
Memory |
Socket | ?2 * Non-ECC SO-DIMM Slot, Dual Channel DDR3 up to 1600MHz |
| ? | Capacity | ?16GB, Single Max. 8GB |
|
Graphics |
Controller | ?Intel? HD Graphics |
|
Ethernet |
Controller | ?4 * Intel i210-AT GbE LAN Chip (10/100/1000 Mbps, with PoE Power socket) ?1 * Intel i218-LM/V GbE LAN Chip (10/100/1000 Mbps) |
|
Storage |
SATA | ?1 * SATA3.0 7P Connector, up to 600MB/s ?1 * SATA2.0 7P Connector, up to 300MB/s |
| ? | mSATA | ?1 * mSATA (SATA3.0, Share slot with Mini PCIe, default) |
|
Expansion Slots |
PCIe | j: 1 * PCIe 2.0 x16
k: 2 * PCI PS: j、k One out of two, Expansion card length≤ 235mm ? |
| ? | Mini PCIe | ?1 * Mini PCIe (PCIe x1 Gen 2 + USB2.0, with 1 * SIM Card, Share slot with mSATA, Opt.) |
|
Front I/O |
Ethernet | ?5 * RJ45 |
| ? | USB | ?2 * USB 5Gbps (Type-A, 5Gbps, Each group of two ports Max. 3A, one port Max. 2.5A) ?4 * USB2.0 (Type-A, Each group of two ports Max. 3A, one port Max. 2.5A) |
| ? | Display | ?1 * DP: max resolution up to 3840*2160 @ 60Hz ?1 * HDMI1.4: max resolution up to 2560*1440 @ 60Hz |
| ? | Audio | ?3 * 3.5mm Jack (Line-out + Line-in + MIC) |
| ? | Serial | ?2 * RS232/422/485 (COM1/2, DB9/M, Full Lanes, BIOS Switch) |
| ? | Button | ?1 * Power Button |
| ? | LED | ?1 * Power status LED ?1 * Hard drive status LED |
|
Internal I/O |
USB | ?2 * USB2.0 (Header) |
| ? | COM | ?4 * RS232 (COM3/4/5/6, Header, Full Lanes) |
| ? | Display | ?1 * eDP: max resolution up to 1920*1200 @ 60Hz (Header) |
| ? | Serial | ?4 * RS232 (COM3/4/5/6, Header) |
| ? | GPIO | ?1 * 8 bits DIO (4xDI and 4xDO, wafer) |
| ? | SATA | ?1 * SATA3.0 7P Connector ?1 * SATA2.0 7P Connector |
| ? | FAN | ?1 * CPU FAN (Header) ?1 * SYS FAN (Header) |
| ? | Front Panel | ?1 * Front Panel (Header) |
|
Power Supply |
Type | ?1U FLEX |
| ? | Power Input Voltage | ?AC power supply, voltage and frequency shall be based on the 1U FLEX power supply provided |
| ? | RTC Battery | ?CR2032 Coin Cell |
|
OS Support |
Windows | ?Windows 7/10/11 |
| ? | Linux | ?Linux |
|
Watchdog |
Output | ?System Reset |
| ? | Interval | ?Programmable 1 ~ 255 sec |
|
Mechanical |
Enclosure Material | ?SGCC+AI6061 |
| ? | Dimensions | ?266mm * 127mm * 268mm |
| ? | Mounting | ?Wall mounted, Desktop |
|
Environment |
Heat Dissipation System | ?PWM fan cooling |
| ? | Operating Temperature | ?0 ~ 50℃ |
| ? | Storage Temperature | ?-20 ~ 75℃ |
| ? | Relative Humidity | ?10 to 95% RH (non-condensing) |
-
